Các loại loa dùng trong, ngoài nhà Yến

Được sự đồng ý và hỗ trợ từ MEIYAN SWIFTLET PRODUCTS từ Malaysia, Công Ty Kim Xuân là nhà phân phối độc quyền tại Việt Nam cho các mặt hàng dưới  đây:

H15 - SUPER CALLER 4 WAYS with HORN TWEETER
Roof top puller.4 HP2000 horn tweeter installed.Very effective to lure birds from a far.Covers 4 sides.Sound travels far but not loud when listen from ground.Also works as a beacon for birds to recognise one's bird house.Recommend for competitive area.


H2 - LONG RANGE BAZOOKA LENGTH 4FT
Sound travels up to 1 km with this bazooka.Suitable for bird house built in the bush.Install 90dg facing upwards for best result.Installed with 4 x MOTOROLA QUALITY tweeters with capacitors.

H7 - PIRO BAZZOKA SLR1000
Long range bazzoka.Range 500m - 1km.Useful to attract birds from far and a must for competitive area.Made in Indonesia.


G11 - HEX FACE UP 45DG CASING
DIY stainless steel casing for those who wants to use other brand of tweeters.Easy to install.


H13 - BLACK HEX with KENWOOD WATER PROOF TWEETER
Installed with 6 small but powerful magnetic tweeters.Capacitors included.Range 300-400m up to the sky.



H12B-HEXAGON CALLER WITH ARROW TWEETER 3x3"
Quality ARROW tweeter from Indonesia.Has a cap to on top.Suitable for roof top caller.





H18-TRIANGLE PULLER
Stainless steel frame with 8 x quality PZ-12 tweeters.Leaning up to attracts flying high swiftlet.


H20-COMBO HEX HP4000 AND TRIANGLE PULLER
A very good combination that covers all side sounding to attracts swiftlet.


G12A-HEXAGON WITH HORN TWEETER
Very powerful and clear sounding.Able to cover of 500m radius.Suitable for stand alone and competitive  area.Extension on top allows extra puller to be installed.


H12A-HEXAGON WITH 3"X7" COILED TWEETERS
Wider range more powerful to attracts swiftlet.Stainless steel casing.Tweeter can be changed easily.


H12 - HEXAGONAL TWEETER with WATER RESISTANT TWEETER
Same function as above hexagon only this one is covered with water resistant film.


H14 - HEXAGON TWEETER 45dg FACE UP
Installed with 6 x MOTOROLA QUALITY tweeters 3"x3" with tweeter guards to prevent birds from breaking the heat resistant film attached.Strong film is water resistant.For roof top use.Range 300m up to the sky.Attracts high flying swiftlet.Stainless steel body.Easy to change faulty tweeter.


H17-HEXAGON WITH HORN TWEETER HP4000
Very powerful and effective in pulling birds from afar.Extra joint on top makes it able to add another caller to make it a powerful combo.Stainless steel frame.


H10- HEXAGON SET with 6 AUDAX AX65 TWEETER
Built with 6 x AUDAX AX65 3"x 4" tweeters.Whole set includes stand and adjustable pole.Front of tweeter is covered with black netting.Range 200 - 300m all sides.Ready to install.



G13A-MINI BAZOOKA CASING

H6- MINI ZOOKA with ROUND HORN TWEETER
Range 300-400m.Suitable to install at entrance hole.Best is the tweeter part not expose to rain.Hole drilled for water drainage.Also can be use at interfloor hole to attracts birds to the lower floor.Installed with a HP2000 horn tweeter.


H4 - THE ZOOKA with ROUND HORN TWEETER
Medium range up to 500m.Stainless steel body for long lasting.Installed with 1 x HP2000.Good sounding to lure birds.Wind cap included.



H19-COMBO HEXAGON HORN TWEETER AND 45DG UP
A very powerful combination.Covers all side including
the top.Able to attracts high flying swiftlets.


H5 - MINI BAZOOKA WITH BRACKETS
Straight stand and side stands included.A HP2000 horn tweeter with 2.5m quality speaker wire.Plastic wind cap to reduce rain water flow in.Good drainage system.Range 500m.Suitable for open roof bird house.Attracts birds from neighbouring bird houses.


H3-NEST TECH SPECIAL BAZOOKA
Shaped to minimize water flowing into the tube.Range of 500m,enough to pull and attract swiftet from neighbouring farms.


H8 - PIRO BAZZOKA PANGGIL SLR900
Super clear tweeter for entrance hole.Quality magnetic tweeter.
Good tweeter attracts more birds especially in competitive area.


F4B-CTS TWEETER KSN-1188
Screw on piezo tweeter.Powerful 400W RMS.Built-In breaker protection.Frequency response of 800Hz-20kHz.Overall diameter 3.75",overall depth 3.0".Sensitivity of 93db SPL.Standard 1.375" thread type.Came with piezo horn lense.



F13 - ARROW PIEZO SUPER TWEETER PCT - 9000
Specs same as PCT-4000

F11 - AUDAX TWEETER AX55S ORIGINAL
Special edition Audax tweeter imported from Indonesia.Suitable for internal use inerfloor and doorway.
Specs same as Audax AX61S
Dimensions : 9cm x 9cm x 10cm


F6 - AUDAX TWEETER AX61A 3"X3"
Internal tweeter.



F10 - AUDAX TWEETER AX61S ORIGINAL 3"X3"
Original special edition Audax tweeter.Imported from Indonesia.Superb sound.Very effective for internal calling.Proven to be good.
Frequency response : 4kHz to 27kHz
Average sensitivity : 95db 1 watt/1m
Maximum power handling : 75W ( 8ohms system reference)
Dimensions : 8.9cm x 8.9cm x 5.5cm


F2 - CTS KSN1141 3"X7" TWEETER
Powerful 400W RMS.Frequency response of 1.8k - 30kHz.Sensitivy of 92db
Break circuit protection.OD - 7.35"W X 3.1"H
Cutout - 6.25"W X 2.215"H
Suitable for external and inter hole use.Super clear.Proven to be very effective to attract birds.


F3 - CTS TWEETER KSN1177 DOUBLE HORN
Suitable for external use.Very clear sounding more powerful.

F7 - AUDAX AX61 with CAPACITOR
Specs same as Audax AX61S.
Soldered capacitor included
For internal calling




F1 - CTS TWEETER KSN1005 3.4"X 3.4"
Imported from USA.Super clear tweeter.Suitable for internal use or interfloor.Natural swiftlet sound.
75W RMS power handling.Frequency response of 4.0k - 27kHz.Sesitivity of 94db.OD - 3.4"W X 3.4"H.Cutout 3"W X 3"H


F44 - AUDIO MASTER MAGNETIC HORN TWEETER 4"X10"
Steel casing.Use for external calling.
F15 - PIRO TWEETER PR83
Imported from Indonesia.One of the top range internal tweeter.Clear and natural sound.
Come with detachable plastic net cover and ready soldered capacitor.
Type: Piezo - Electric super horn tweeter
Continuous peak program power : 75W
Intermitent peak power : 150W
Efficiency : 92db / 1 watt at 1m
Impedance : Over 1.500 ohms/1.2kHz and 55 ohms/40kHz
Frequency response : 3k - 40kHz
Size : L10cm x 1W0cm x D5cm




F14 - PIRO TWEETER PR89
All specs same as PR83.
Size : 14cmL x 8 cmW x 5cmD


F12 - ARROW PIEZO SUPER TWEETER PCT-4000
Continuous peak program : 75watt
Intermittent peak power : 150watt
Efficiency : 92dB/1 watt at 1 m
Impedance : over 1.500 ohms/1.2 KHz & 55 ohms/40KHz
Frequency response : 3k Hz - 40k Hz
Imported from Indonesia.Clear sound suitable for internal use.


F13 - ARROW PIEZO SUPER TWEETER PCT - 9000
Specs same as PCT-4000


F4 - CTS TWEETER SCREW ON KSN-1142
Imported from USA.Powerline original CTS made in Philipines.Screw on to a 4"x10" cutout.Use for external call or door way.Some install one at the back of bird house to lure birds in.Powerful 400W RMS.Frequency response of 1.8k - 30kHz.Sensitivity of 92db with break circuit protection.Came with piezo horn lense.


F42 - HORN TWEETER HP4000 3"X7"
Diameter x Depth : 188mm x 78mm x 113mm
Specs same as HP1000


F41 - HORN TWEETER HP3000
Diameter x Depth : 88mm x 98.5mm
Specs same as HP1000


F40 - HORN TWEETER HP2000
Diameter x Depth : 106mm x 82.5mm
Specs same as HP1000


F39 - HORN TWEETER HP1000
Material : Engineering plastic
Nominal impedance : 8 ohm
Power capacity : 20Watts RMS
Sensitivity : 106db
Frequency range : 1.5kHz - 18kHz
Diaphragm material : Phenolic
Magnet : Neodymium H-38
Diameter x Depth : 86mm x 82.5mm
Loud and clear horn tweeter.A real bird puller.Suitable for external,interhole and doorway calling.


F43 - HORN TWEETER HP5000
Impedance : 8ohm
Power handling : 20W
Sensitivity : 107db
Frequency range : 1.5k - 20kHz
Recommended crossover : 2.5kHz or higher
Voice coil diameter : 25.4mm
Flux density : 1.6T
                                                             Diaphram material : Titanium
Use for external calling,loud and clear


F25 - TECNIK SUPER TWEETER 2"X4"
Suitable for external calling.Powerful and good sound.

F5 - AUDAX TWEETER AX60 3"X3"
For internal calling.Specs same as Audax AX61S

F36 -PZ-8 MOTOROLA QUALITY with CAPACITOR 3"x 3"
F37 - PZ-12 MOTOROLA QUALITY with CAPACITOR 2"X5"
Come with copper coil and capacitor.Very good for external and door way calling.
Frequency range : 5k - 20kHz
Dispersion : 40dgH x 55dgV - 6db points
Sensitivity : 105db
Impedance : 4 or 8 ohms
Dimensions : 67mm x 145mm x 60mm


F38 - PZ-16 MOTOROLA QUALITY with CAPACITOR 3"X7"
For external use.
Power RMS/MAX : 150W/300W
Dimensions : 77mm x 185mm x 120mm
Others same as PZ-8 and PZ-12


F47 - WATERPROOF TWEETER SP-PT-338
Dimensions : 8cmH x 22cmW x 12.5cmD
                                                                    For external use.

F17 - TECNIK ROUND TWEETER 4" 150W
Suitable for internal use.Clear sound and good quality.


F25-FUJIBIN TWEETER FB-PT33 Size 3"X3"
Specs same as F26



F27 - TECNIK TWEETER FB-PT44 4"X4"
Suitable for doorway and interfloor hole calling.
Dimensions : 77mmH x 112mmW x 112mmD
Specs same as FB-PT25


F26- FUJIBIN TWEETER FB-PT25 Size 2"X5"
High Articulation Piezo Tweeter
Suitable for internal calling.Striped surface.
Frequency response : 0kHz - 30kHz
Average sensitiviy : 105 db 1 Watt/1 meter
Maximum power handling capacity: 75W (8 ohm reference)
Maximum voltage : 15V rms continuous
35V rms intermittent.Dimensions : 57mm x 147mm x 70mm


F28- SWALLOW SOUND TWEETER 3"X3"
F29- SWALLOW SOUND TWEETER 2"X5"
For internal calling.


F27A-MEIYAN ABC INTERNAL TWEETER 2"X5"
F16 - TECNIK TWEETER 2"X5"
For internal calling.Only available in 2"x5".


F50 - 4 CORNER WITH AUDAX AX61 TWEETER
For internal calling.Install in the middle of bird house.


F49 - 4 CORNER WITH SWALLOW TWEETER
For internal calling.Install in the middle plank of bird house.



G12-HEXAGON CASING FOR ANY 3"X7" TWEETER
Stainless steel


G12A-HEX CASING FOR HORN TWEETER HP5000/TECNIK AXC400
Stainless steel casing for those who like to DIY.


G12B-STAINLESS STEEL CASING FOR 3" X 3" TWEETER

G10 - HEXAGON STAINLESS STEEL CASING
DIY to build a hexagon tweeter using tweeters of one's choice.Fits all 2"x5" tweeters.

G9 - STEEL BRACKET NON ADJUSTABLE
Side way stand to be nail to the wall to hold a pole for roof top caller.



G7 - STAINLESS STEEL BRACKET NON ADJUSTABLE
Same as above only this one is stainless steel.


G8 - STEEL EXTENDABLE POLE
Maximum strecth 5.5ft.To install roof top tweeters such as hexagonal tweeter.


G6 - STAINLESS STEEL BRACKET ADJUSTABLE
Stainless steel can be adjusted as straight or side way stand.


G3 - HORN TWEETER REPLACEMENT COIL
Replacement coil for all horn tweeters
F45 - KENWOOD WATERPROOF MAGNETIC TWEETER
Only 5 cm in diameter.Powerful and water proof.Suitable for external and internal calling.


F46 - WATER RESISTANT TWEETER WITH GUARD
Covered by a fine thin but strong film to prevent rain drops from going into the tweeter.
Steel guard to avoid birds scratching and tear the film.Suitable for external use.

F22 - TECNIK TWEETER SP-PT-AX50
Piezo tweeter with curve front.Suitable for internal and doorway use

F23 - TECNIK TWEETER SP-PT-AX63 4"X4"
Piezo tweeter.Suitable for doorway and interfloor hole calling.

F21 - TECNIK TWEETER SP-PT-AX62 3"X3"
Piezo tweeter for internal use.

F18 - TECNIK TWEETER AX305 2"X5"
Internal calling tweeter.Sound is clear and natural.


F19 - TECNIK TWEETER AX61/AX96 4"X4"
Piezo tweeter for doorway and interfloor hole calling.


F20 - TECNIK TWEETER AX65 3"X4"
Piezo tweeter for doorway and interfloor hole calling.


F24 - TECNIK SP-PT-305BC
Tecnik Pro-Series 350W Super tweeter.
Frequency response :5k - 20k
Sensitivity : 98db (1W/1M)
Power RMS/MAX : 100/350Watts
Impedance : 4-8 ohms
Dimensions : 145mm x 55mm x 73mm

G1 - 4 CORNER DIY STAINLESS STEEL FRAME
Suits 3"x 3" and 2" x 5"  tweeters.

F51-OCTAGON INTERNAL TWEETER
Suitable for internal use.Install in the middle of nesting room to attracts swiftlet to nest around it.

G1A-STAINLESS STEEL OCTAGON DIY FRAME
For internal use.Suits 2"x5" internal tweeter.

H9 - PIRO MINI BAZZOKA SLR800
Medium range caller.300 to 500m range.Also suitable for multi storeys bird house to attract birds to explore lower floor.Quality magnetic tweeter,clear sounding.
Made in Indonesia.
